HIGHFIELD PA420

$22,780.00

Yamaha Motor Finance

APPLY
Description

The Patrol range of commercial quality RIBs are designed to work both excellently as a long distance family cruiser or a hardcore work boat. Built to withstand the toughest of conditions.

The hull is built from 5083 aluminium plates with 6 and 10mm stringers. With their super deep V, wide chines and large diameter tube, they offer high manoeuvrability, high safety and a soft dry ride even in the roughest conditions.

The range offers something for almost every requirement, from Sailing club support to Police and Rescue applications.

The Patrol boats carry large loads and plane quickly and easily with little horse-power. For charter boat and commercial operators, the modular set-up option means that we can build a layout that suits your needs. These boats are ideal pursuit craft or work boats and can be configured with different seating and console options. When safety, toughness & reliability really matter, the Patrol range should be your first port of call. With MCA rating & commercial coding available, the Patrol range is perfect for commercial chartering or working offshore too.

STANDARD FEATURES

  • ORCA® Hypalon or PVC tube
  • Welded seams (PVC)
  • Flush mount non-return valves
  • High tensile chromated & powder coated aluminum hull
  • Integrated transom supports
  • Self-draining deck
  • Steering wheel
  • Integrated under-deck fuel tank
  • Lifting points and towing eyes
  • Tow bridle points
  • Anti-slip deck
  • Heavy duty rubbing strake
  • Keel guard
  • Highfield dry bag
  • Foot pump, oars, repair kit
  • Carbon dash
  • Electrical pack for console
  • Electrical pack for boat
  • Transom ladder

OPTIONAL EQUIPMENT

  • Console & seat options
  • Rear Tow Post
  • Roll Bar
  • Suspension seat with shock



    OVERALL LENGTH 4.21 m 13' 10"
    INTERNAL LENGTH 3.17 m 10' 5"
    OVERALL WIDTH 2.11 m 6' 11"
    INTERNAL WIDTH 1.05 m 3' 5"
    DEAD RISE 20°
    TUBE DIAMETER 47 cm 19"
    NUMBER OF AIR CHAMBERS 4
    MAXIMUM LOAD 885 kg 1951 lb
    MAXIMUM PEOPLE 8
    BOAT WEIGHT* 252 kg 556 lb
    MAXIMUM POWER 60 hp
    ENGINE SHAFT L
    FUEL TANK 55 l 14.5 gal
    DESIGN CATEGORY C

    *Includes console, rear seat & rollbar


Technical Specifications

Engine Type 4-stroke, 4-cyl DOHC, 16-Valve, High Output Marine Engine

Displacement (cc) 1812.0

Pressure Pump 155mm High-Pressure Axial Flow

Bore x Stroke (mm) 86 x 78

Compression Ratio 11.0 : 1

Lubrication System Scavenger Pump Assisted Wet Sump

Fuel Management Electronic Fuel Injection

Fuel Tank Capacity (L)70.0

Storage Capacity 168

Length (mm) 3580

Width (mm) 1270

Height (mm) 1230

Dry Weight (kg)389
